Dosimetric Comparison of Various Treatment Techniques for Post-Mastectomy Breast Radiotherapy: Evaluation of a Novel Hybrid IMRT Approach in Nepal Novel hybrid IMRT approach
Abstract
Background: Radiotherapy is integral to breast cancer treatment and is a crucial adjuvant therapy alongside a combination of surgery and chemotherapy in Nepal. The study was designed to assess the impact of hybrid intensity-modulated radiotherapy (h-IMRT) on tumor response, determine its role in improving overall survival, and compare different radiotherapy techniques, including field-in-field (FiF), intensity-modulated radiotherapy (IMRT), with h-IMRT.
Methods: Twenty-five left-sided breast cancer patients were included for plan evaluation in terms of planning target volume (PTV) coverage and organ at risk (OAR) irradiation. Patients who underwent modified radical mastectomy were planned in Eclipse 13.6 treatment planning system (TPS) for 40.05 Gy in 15 fractions, using FiF, IMRT, and h-IMRT separately. The PTV included the left chest wall, axillary nodes, and supraclavicular nodes.
Results: The Dmean (mean dose) within the PTV was lowest in IMRT and increased by 1.52% in the h-IMRT plan. The study showed that the lowest Dmean for the heart was in the h-IMRT plan, while it increased by 45% in the FiF plan. The V20 and V10 of the heart as good indicators of the heart risk were minimal in the h-IMRT plan compared to FiF and IMRT. The lung volume receiving a dose equal to or greater than 20 Gy (V20) was also minimal in the h-IMRT plan compared to IMRT and FiF.
Conclusion: The h-IMRT treatment plan for left-sided breast cancer provides better PTV dose coverage and OAR sparing compared to FiF and IMRT plans. The h-IMRT plan also reduces monitor unit (MU) count.
Full text article
References
Bray F, Ferlay J, Soerjomataram I, Siegel RL, Torre LA, Jemal A. Global cancer statistics 2018: GLOBOCAN estimates of incidence and mortality worldwide for 36 cancers in 185 countries. CA: a cancer journal for clinicians. 2018;68(6):394–424. doi:10.3322/caac.21492.
Forouzanfar MH, Foreman KJ, Delossantos AM, Lozano R, Lopez AD, Murray CJL, et al. Breast and cervical cancer in 187 countries between 1980 and 2010: a systematic analysis. The Lancet. 2011 Oct 22;378(9801):1461–84. doi: 10.1016/S0140-6736(11)61351-2.
Kwong DLW, McGale P, Taylor C, Correa C, Cutter D, Duane F, et al. Effect of radiotherapy after mastectomy and axillary surgery on 10-year recurrence and 20-year breast cancer mortality: meta-analysis of individual patient data for 8135 women in 22 randomised trials. The Lancet [Internet]. 2014. doi:10.1016/S0140-6736(14)60488-8.
Balaji K, Subramanian B, Yadav P, Radha CA, Ramasubramanian V. Radiation therapy for breast cancer: Literature review. Medical Dosimetry. 2016;41(3):253–7. doi:10.1016/j.meddos.2016.06.005.
Schubert LK, Gondi V, Sengbusch E, Westerly DC, Soisson ET, Paliwal BR, et al. Dosimetric comparison of left-sided whole breast irradiation with 3DCRT, forward-planned IMRT, inverse-planned IMRT, helical tomotherapy, and topotherapy. Radiotherapy and Oncology. 2011;100(2):241–6. doi:10.1016/j.radonc.2011.01.004.
Yavas G, Yavas C, Acar H. Dosimetric comparison of whole breast radiotherapy using field in field and conformal radiotherapy techniques in early stage breast cancer. International Journal of Radiation Research. 2012;10(3/4):131-138. Available from: http://ijrr.com/article-1-979-en.html
Lee JW, Hong S, Choi KS, Kim YL, Park BM, Chung JB, et al. Performance evaluation of field-in-field technique for tangential breast irradiation. Japanese journal of clinical oncology. 2008;38(2):158–63. doi:10.1093/jjco/hym167.
Barnett GC, Wilkinson JS, Moody AM, Wilson CB, Twyman N, Wishart GC, et al. Randomized Controlled Trial of Forward-Planned Intensity Modulated Radiotherapy for Early Breast Cancer: Interim Results at 2 Years. International Journal of Radiation Oncology*Biology*Physics. 2012 Feb 1;82(2):715–23. doi:10.1016/j.ijrobp.2010.10.068.
Selvaraj RN, Beriwal S, Pourarian RJ, Lalonde RJ, Chen A, Mehta K, et al. Clinical implementation of tangential field intensity modulated radiation therapy (IMRT) using sliding window technique and dosimetric comparison with 3D conformal therapy (3DCRT) in breast cancer. Medical Dosimetry. 2007;32(4):299–304. doi:10.1016/j.meddos.2007.03.001.
Mayo CS, Urie MM, Fitzgerald TJ. Hybrid IMRT plans—concurrently treating conventional and IMRT beams for improved breast irradiation and reduced planning time. International Journal of Radiation Oncology* Biology* Physics. 2005;61(3):922–32. doi:10.1016/j.ijrobp.2004.10.033.
Farace P, Zucca S, Solla I, Fadda G, Durzu S, Porru S, et al. Planning hybrid intensity modulated radiation therapy for whole-breast irradiation. International Journal of Radiation Oncology* Biology* Physics. 2012;84(1):e115–22. doi:10.1016/j.ijrobp.2012.02.025.
Shiau AC, Hsieh CH, Tien HJ, Yeh HP, Lin CT, Shueng PW, et al. Left-Sided Whole Breast Irradiation with Hybrid-IMRT and Helical Tomotherapy Dosimetric Comparison. BioMed Research International. 2014;2014:1–7 doi:10.1155/2014/741326.
Prescribing R. Reporting intensity-modulated photon-beam therapy (IMRT)(ICRU Report 83) ICRU Report 83. J ICRU. 2010;10.
Johansen S, Cozzi L, Olsen DR. A planning comparison of dose patterns in organs at risk and predicted risk for radiation induced malignancy in the contralateral breast following radiation therapy of primary breast using conventional, IMRT and Volumetric modulated arc treatment techniques. Acta Oncologica. 2009 Jan;48(4):495–503. doi:10.1080/02841860802657227.
Qiao L, Xie J, Cheng J, Liang N, Deng G, Zhang J, et al. SU‐E‐P‐51: Dosimetric Comparison to Organs at Risk Sparing Using Volumetric‐Modulated Arc Therapy Versus Intensity‐Modulated Radiotherapy in Postoperative Radiotherapy of Left‐Sided Breast Cancer. Medical Physics. 2015 Jun;42(6Part5):3238–3238. doi:10.1118/1.4923985.
Xie X, Ouyang S, Wang H, Yang W, Jin H, Hu B, et al. Dosimetric comparison of left-sided whole breast irradiation with 3D-CRT, IP-IMRT and hybrid IMRT. Oncology reports. 2014;31(5):2195–205. doi:10.3892/or.2014.3058.
Nakamura N, Takahashi O, Kamo M, Hatanaka S, Endo H, Mizuno N, et al. Effects of geometrical uncertainties on whole breast radiotherapy: a comparison of four different techniques. Journal of Breast Cancer. 2014;17(2):157–60. doi:10.4048/jbc.2014.17.2.157.
Fogliata A, De Rose F, Franceschini D, Stravato A, Seppälä J, Scorsetti M, et al. Critical appraisal of the risk of secondary cancer induction from breast radiation therapy with volumetric modulated arc therapy relative to 3D conformal therapy. International Journal of Radiation Oncology* Biology* Physics. 2018;100(3):785–93. doi:10.1016/j.ijrobp.2017.10.040.
Stovall M, Smith SA, Langholz BM, Boice Jr JD, Shore RE, Andersson M, et al. Dose to the contralateral breast from radiotherapy and risk of second primary breast cancer in the WECARE study. International Journal of Radiation Oncology* Biology* Physics. 2008;72(4):1021–30. doi:10.1016/j.ijrobp.2008.02.040.
Ding Z, Zeng Q, Kang K, Xu M, Xiang X, Liu C. Evaluation of plan robustness using hybrid intensity-modulated radiotherapy (IMRT) and volumetric arc modulation radiotherapy (VMAT) for left-sided breast cancer. Bioengineering. 2022;9(4):131. doi:10.3390/bioengineering9040131.
Racka I, Majewska K, Winiecki J, Kiluk K. Hybrid planning techniques for early-stage left-sided breast cancer: dose distribution analysis and estimation of projected secondary cancer-relative risk. Acta Oncologica. 2023 Aug 3;62(8): 932-41. doi:10.1080/0284186X.2023.2238553.
Hall EJ, Wuu CS. Radiation-induced second cancers: the impact of 3D-CRT and IMRT. International Journal of Radiation Oncology* Biology* Physics. 2003;56(1):83–8. doi:10.1016/S0360-3016(03)00073-7.
Srivastava RP, Basta K, De Gersem W, De Wagter C. A comparative analysis of Acuros XB and the analytical anisotropic algorithm for volumetric modulation arc therapy. Reports of Practical oncology and Radiotherapy. 2021;26(3):481–8. doi:10.5603/RPOR.a2021.0050.
